Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Big Block 440 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.360 Bore, 1.485 CD, 0.990 Pin, Set of 8. |
| Description_EXT |
SRP, Chrysler, Big Block Chrysler, 4.360 in. Bore, 1.485 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Chrysler 440, 4.360 Bore, Dish, Set of 8 |
| Ringset Included |
No |
| Oil Ring Thickness |
0.188 |
| Title |
SRP - Chrysler, Big Block, 4.360 in. Bore, Piston Kit |
| Top Compression Ring Thickness |
0.0640 |
| Piston Series |
SRP |
| Piston Head Type |
Dish |
| Forging Type |
FSR |
| Make |
CHRYSLER |
| Piston Average Weight |
605 |
| Bore Diameter |
4.360 |
| Piston Pin Material |
5115 |
| Product Market |
Domestic |
| Wrist Pin Wall Thickness |
0.180 |
| Engine - Web |
Big Block |
| Industry |
Automotive |
| Add-On |
S100S8-4360-5 |
| Piston Pin Wall Thickness |
0.180 |
| Add-On |
990-2930-18-51S |
| Product Type |
Engine Piston Kit |
| Compression Height |
1.485 |
| Piston Pin Outside Diameter |
0.990 |
| Engine Type |
ICE |
| Add-On |
990-042-CS |
| Piston Material |
4032 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.930 |
| Wrist Pin Outer Diameter |
0.990 |
| Piston Pin Length |
2.930 |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0640 |
| Cylinder Head |
440 WEDGE |
| Out of Stock Message |
Call for Availability |
| Prop 65 (C, R or CR) |
CR |
| Engine |
Big Block |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Volume |
-24.00 |
| Title - Web |
SRP Chrysler Big Block Piston Kit - 4.360 in. Bore - 1.485 in. CH, -24.00 CC |
| Ring Set Included |
No |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chrysler |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
16.0000 |
