As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet LT1 Gen V |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 4.070 Bore, 1.326 CD, 0.943 Pin, Set of 8. |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Chevrolet, LT1 Gen V, 4.070 in. Bore, 1.326 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Chevrolet LT1, 4.070 Bore, Dish, Set of 8 |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Cylinder Head |
GEN 5 LT1 |
| Second Compression Ring Thickness |
0.0600 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Material |
2618 |
| Add-On |
945-073-MW |
| Out of Stock Message |
Call for Availability |
| Add-On |
JG31F1-4070-0 |
| Ringset Included |
Yes |
| Piston Pin Length |
2.250 |
| Add-On |
943-2250-20-51C |
| Make - Web |
Chevrolet |
| Product Type |
Engine Piston Kit |
| Piston Quantity |
8 |
| Industry |
Automotive |
| Piston Pin Material |
5115 |
| Title - Web |
JE Pistons Chevrolet LT1 Gen V Piston Kit - 4.070 in. Bore - 1.326 in. CH, -14.10 CC |
| Engine Type |
ICE |
| Engine |
LT1 Gen V |
| Forging Type |
FSR |
| Compression Height |
1.326 |
| Engine - Web |
LT1 Gen V |
| Wrist Pin Length |
2.250 |
| Wrist Pin Outer Diameter |
0.943 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Make |
CHEVROLET |
| Top Compression Ring Thickness |
0.0480 |
| Product Market |
Domestic |
| Piston Average Weight |
474 |
| Piston Series |
JE Pistons |
| Bore Diameter |
4.070 |
| Title |
JE Pistons - Chevrolet, LT1 Gen V, 4.070 in. Bore, Piston Kit |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Piston Pin Wall Thickness |
0.200 |
| Piston Pin Outside Diameter |
0.943 |
| Piston Volume |
-14.10 |
| Oil Ring Thickness |
0.1175 |
| Piston Head Type |
Dish |
| Wrist Pin Wall Thickness |
0.200 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
