As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ford 3.5L Ecoboost Gen II V6 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.661 Bore, 1.240 CD, 0.905 Pin, Set of 6. |
| Description_EXT |
JE, Ford, 3.5L EcoBoost Gen 2 V6, 3.661 in. Bore, 10.00:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Ford 3.5L Eco Boost V6, 93.00 Bore, Dish, Set of 6 |
| Description_SHO |
Piston Kit |
| Wrist Pin Outer Diameter |
0.905 |
| Piston Pin Length |
2.250 |
| Piston Pin Outside Diameter |
0.905 |
| Product Market |
Sport Compact |
| Piston Series |
JE Pistons |
| Make |
FORD |
| Piston Head Type |
Dish |
| Title |
JE Pistons - Ford, 3.5L EcoBoost Gen 2 V6, 93.00 mm Bore, Piston Kit |
| Wrist Pin Wall Thickness |
0.180 |
| Piston Pin Wall Thickness |
0.180 |
| Oil Ring Thickness |
0.111 |
| Piston Pin Material |
5115 |
| Piston Quantity |
6 |
| Bore Diameter |
93.00 |
| Industry |
Automotive |
| Top Compression Ring Thickness |
0.0400 |
| Engine Type |
ICE |
| Piston Average Weight |
392 |
| Cylinder Head |
ECOBOOST V6 |
| Engine |
3.5L ECOBOOST GEN 2 V6 |
| Compression Height |
1.240 |
| Forging Type |
FSR |
| Ringset Included |
Yes |
| Engine - Web |
3.5L EcoBoost Gen 2 V6 |
| Add-On |
905-073-MW |
| Product Type |
Engine Piston Kit |
| Piston Volume |
-13.10 |
| Prop 65 (C, R or CR) |
CR |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Out of Stock Message |
Call for Availability |
| Add-On |
JG1001-3661 |
| Second Compression Ring Thickness |
0.0480 |
| Title - Web |
JE Pistons Ford 3.5L EcoBoost Gen 2 V6 Piston Kit - 93.00 mm Bore - 1.240 in. CH, -13.10 CC |
| Piston Material |
2618 |
| Prop 65 Yes/No |
Yes |
| Add-On |
905-2250-18-51C |
| Make - Web |
Ford |
| Ring Set Included |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Length |
2.250 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
8.0000 |
