As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.0T TSI 2013+ |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.248 Bore, 1.165 CD, 0.866 Pin, Set of 4. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, VW, 2.0T TSI - 13-15 - 22mm Pin, 3.248 in. Bore, 9.60:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_TLE |
Volkswagen 2.0L Turbo, 82.50 Bore, Dish, Set of 4 |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Piston Pin Length |
2.250 |
| Piston Head Type |
Dish |
| Piston Series |
JE Pistons |
| Piston Pin Material |
5115 |
| Second Compression Ring Thickness |
0.0480 |
| Title - Web |
JE Pistons Volkswagen 2.0T TSI Piston Kit - 82.50 mm Bore - 1.165 in. CH, -7.10 CC |
| Engine |
2.0T TSI 2013-2015 22 mm Pin |
| Engine Type |
ICE |
| Oil Ring Thickness |
0.111 |
| Forging Type |
FSR |
| Ringset Included |
Yes |
| Make - Web |
Volkswagen |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine Detail |
2.0T TSI 2013-2015 22 mm Pin |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Product Market |
European |
| Piston Pin Wall Thickness |
0.150 |
| Piston Volume |
-7.10 |
| Cylinder Head |
2.0 TSI |
| Top Compression Ring Thickness |
0.0400 |
| Add-On |
JG1001-3250 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Out of Stock Message |
Call for Availability |
| Add-On |
866-2250-15-51C |
| Compression Height |
1.165 |
| Make |
VOLKSWAGEN |
| Piston Material |
2618 |
| Piston Quantity |
4 |
| Add-On |
866-063-MW |
| Piston Pin Outside Diameter |
0.866 |
| Title |
JE Pistons - Volkswagen, 2.0T TSI, 82.50 mm Bore, Piston Kit |
| Bore Diameter |
82.50 |
| Prop 65 Yes/No |
Yes |
| Industry |
Automotive |
| Product Type |
Engine Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Engine - Web |
2.0T TSI |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
7.0000 |
