As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.0T TSI 2013+ |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.268 Bore, 1.165 CD, 0.866 Pin, Set of 4. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, VW, 2.0T TSI - 13-15 - 22mm Pin, 3.268 in. Bore, 9.60:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Volkswagen 2.0L Turbo, 83.00 Bore, Dish, Set of 4 |
| Piston Volume |
-7.80 |
| Product Type |
Engine Piston Kit |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Prop 65 (C, R or CR) |
CR |
| Piston Material |
2618 |
| Piston Quantity |
4 |
| Cylinder Head |
2.0 TSI |
| Industry |
Automotive |
| Top Compression Ring Thickness |
0.0400 |
| Ring Set Included |
Yes |
| Second Compression Ring Thickness |
0.0480 |
| Wrist Pin Length |
2.250 |
| Make - Web |
Volkswagen |
| Piston Pin Length |
2.250 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Prop 65 Yes/No |
Yes |
| Title - Web |
JE Pistons Volkswagen 2.0T TSI Piston Kit - 83.00 mm Bore - 1.165 in. CH, -7.80 CC |
| Out of Stock Message |
Call for Availability |
| Bore Diameter |
83.00 |
| Add-On |
866-063-MW |
| Add-On |
JG1001-3268 |
| Add-On |
866-2250-15-51C |
| Engine Detail |
2.0T TSI 2013-2015 22 mm Pin |
| Piston Pin Outside Diameter |
0.866 |
| Ringset Included |
Yes |
| Title |
JE Pistons - Volkswagen, 2.0T TSI, 83.00 mm Bore, Piston Kit |
| Piston Pin Material |
5115 |
| Engine |
2.0T TSI 2013-2015 22 mm Pin |
| Oil Ring Thickness |
0.111 |
| Piston Head Type |
Dish |
| Compression Height |
1.165 |
| Forging Type |
FSR |
| Make |
VOLKSWAGEN |
| Piston Pin Wall Thickness |
0.150 |
| Piston Series |
JE Pistons |
| Product Market |
European |
| Engine Type |
ICE |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.150 |
| Engine - Web |
2.0T TSI |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
7.0000 |
