Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 351C |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.060 Bore, 1.660 CD, 0.912 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.060 in. Bore, 1.660 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford 351 Cleveland, 4.060 Bore, Flat, Set of 8 |
| Engine |
Small Block |
| Add-On |
912-2750-14-51S |
| Out of Stock Message |
Call for Availability |
| Add-On |
S100S8-4060-5 |
| Add-On |
927-042-CS |
| Product Type |
Engine Piston Kit |
| Piston Pin Length |
2.750 |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.060 in. Bore - 1.660 in. CH, -3.00 CC |
| Prop 65 Yes/No |
Yes |
| Piston Material |
4032 |
| Piston Volume |
-3.00 |
| Second Compression Ring Thickness |
0.0640 |
| Prop 65 (C, R or CR) |
CR |
| Cylinder Head |
CLEVELAND |
| Forging Type |
FSR |
| Industry |
Automotive |
| Piston Pin Outside Diameter |
0.912 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Ford |
| Wrist Pin Outer Diameter |
0.912 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Average Weight |
553 |
| Make |
FORD |
| Piston Pin Material |
5115 |
| Bore Diameter |
4.060 |
| Top Compression Ring Thickness |
0.0640 |
| Oil Ring Thickness |
0.188 |
| Piston Series |
SRP |
| Ringset Included |
No |
| Title |
SRP - Ford, Small Block, 4.060 in. Bore, Piston Kit |
| Engine Type |
ICE |
| Compression Height |
1.660 |
| Piston Pin Wall Thickness |
0.140 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Head Type |
Flat |
| Product Market |
Domestic |
| Engine - Web |
Small Block |
| Ring Set Included |
No |
| Wrist Pin Wall Thickness |
0.140 |
| Wrist Pin Length |
2.750 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
