Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 302 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 4.010 Bore, 1.600 CD, 0.912 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.010 in. Bore, 1.600 CD, Dome, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 302, 4.010 Bore, Dome, Set of 8 |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Out of Stock Message |
Call for Availability |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0640 |
| Engine |
Small Block |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.010 in. Bore - 1.600 in. CH, 18.00 CC |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Ford |
| Add-On |
J100F8-4010-0 |
| Ringset Included |
No |
| Add-On |
912-2750-14-51S |
| Add-On |
927-042-CS |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Piston Material |
2618 |
| Industry |
Automotive |
| Piston Head Type |
Dome |
| Product Type |
Engine Piston Kit |
| Piston Pin Length |
2.750 |
| Wrist Pin Length |
2.750 |
| Ring Set Included |
No |
| Oil Ring Thickness |
0.188 |
| Make |
FORD |
| Piston Pin Wall Thickness |
0.140 |
| Engine Type |
ICE |
| Top Compression Ring Thickness |
0.0640 |
| Forging Type |
FSR |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Series |
SRP |
| Product Market |
Domestic |
| Piston Pin Outside Diameter |
0.912 |
| Title |
SRP - Ford, Small Block, 4.010 in. Bore, Piston Kit |
| Piston Pin Material |
5115 |
| Piston Volume |
18.00 |
| Bore Diameter |
4.010 |
| Compression Height |
1.600 |
| Engine - Web |
Small Block |
| Wrist Pin Outer Diameter |
0.912 |
| Wrist Pin Wall Thickness |
0.140 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
