SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.010 Bore, 1.560 CD, 0.927 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_INV |
SRP Pro, Piston Set |
| Description_EXT |
SRP Pro 4032, Chevrolet, Small Block Chevrolet, 4.010 in. Bore, 1.560 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 350, 4.010 Bore, Dish, Set of 8 |
| Piston Series |
SRP Pro 4032 |
| Engine |
Small Block |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Ringset Included |
Yes |
| Title - Web |
SRP Pro 4032 Chevrolet Small Block Piston Kit - 4.010 in. Bore - 1.560 in. CH, -24.00 CC |
| Make |
CHEVROLET |
| Piston Pin Material |
5115 |
| Forging Type |
FSR |
| Wrist Pin Outer Diameter |
0.927 |
| Piston Average Weight |
455 |
| Engine Type |
ICE |
| Piston Head Type |
Dish |
| Piston Pin Outside Diameter |
0.927 |
| Compression Height |
1.560 |
| Bore Diameter |
4.010 |
| Oil Ring Thickness |
0.119 |
| Product Type |
Engine Piston Kit |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Length |
2.250 |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Product Market |
Domestic |
| Ring Set Included |
Yes |
| Wrist Pin Wall Thickness |
0.150 |
| Engine - Web |
Small Block |
| Second Compression Ring Thickness |
0.0600 |
| Add-On |
927-2250-15-51C |
| Prop 65 (C, R or CR) |
CR |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Piston Material |
4032 |
| Top Compression Ring Thickness |
0.0480 |
| Industry |
Automotive |
| Add-On |
JG3101-4010-4 |
| Piston Volume |
-24.00 |
| Prop 65 Yes/No |
Yes |
| Title |
SRP Pro 4032 - Chevrolet, Small Block, 4.010 in. Bore, Piston Kit |
| Out of Stock Message |
Call for Availability |
| Add-On |
927-073-MW |
| Wrist Pin Length |
2.250 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
12.0000 |
