SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.010 Bore, 1.000 CD, 0.927 Pin, Set of 8. |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
SRP Pro 4032, Chevrolet, Small Block Chevrolet, 4.010 in. Bore, 1.000 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_INV |
SRP Pro, Piston Set |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_TLE |
Chevrolet 350, 4.010 Bore, Dish, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Piston Pin Outside Diameter |
0.927 |
| Piston Pin Material |
5115 |
| Wrist Pin Outer Diameter |
0.927 |
| Forging Type |
FSR |
| Engine Type |
ICE |
| Wrist Pin Length |
2.250 |
| Oil Ring Thickness |
0.149 |
| Piston Series |
SRP Pro 4032 |
| Compression Height |
1.000 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Head Type |
Dish |
| Title |
SRP Pro 4032 - Chevrolet, Small Block, 4.010 in. Bore, Piston Kit |
| Prop 65 Yes/No |
Yes |
| Top Compression Ring Thickness |
0.0480 |
| Ringset Included |
Yes |
| Make |
CHEVROLET |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Piston Average Weight |
334 |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Product Market |
Domestic |
| Bore Diameter |
4.010 |
| Title - Web |
SRP Pro 4032 Chevrolet Small Block Piston Kit - 4.010 in. Bore - 1.000 in. CH, -16.00 CC |
| Prop 65 (C, R or CR) |
CR |
| Wrist Pin Wall Thickness |
0.150 |
| Engine - Web |
Small Block |
| Piston Pin Length |
2.250 |
| Add-On |
927-073-MW |
| Out of Stock Message |
Call for Availability |
| Piston Volume |
-16.00 |
| Piston Material |
4032 |
| Engine |
Small Block |
| Add-On |
JG3101-4010-4 |
| Product Type |
Engine Piston Kit |
| Second Compression Ring Thickness |
0.0600 |
| Industry |
Automotive |
| Add-On |
927-2250-15-51C |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
Yes |
| Make - Web |
Chevrolet |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
12.0000 |
