SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.020 Bore, 1.560 CD, 0.927 Pin, Set of 8. |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
SRP Pro 4032, Chevrolet, Small Block Chevrolet, 4.020 in. Bore, 1.560 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_INV |
SRP Pro, Piston Set |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_TLE |
Chevrolet 350, 4.020 Bore, Dish, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Product Type |
Engine Piston Kit |
| Piston Volume |
-24.00 |
| Engine - Web |
Small Block |
| Out of Stock Message |
Call for Availability |
| Title |
SRP Pro 4032 - Chevrolet, Small Block, 4.020 in. Bore, Piston Kit |
| Piston Average Weight |
457 |
| Add-On |
JG3101-4020-2 |
| Industry |
Automotive |
| Bore Diameter |
4.020 |
| Piston Pin Wall Thickness |
0.150 |
| Product Market |
Domestic |
| Compression Height |
1.560 |
| Top Compression Ring Thickness |
0.0480 |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Make |
CHEVROLET |
| Add-On |
927-073-MW |
| Add-On |
927-2250-15-51C |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Prop 65 (C, R or CR) |
CR |
| Oil Ring Thickness |
0.119 |
| Piston Pin Outside Diameter |
0.927 |
| Piston Material |
4032 |
| Prop 65 Yes/No |
Yes |
| Piston Pin Length |
2.250 |
| Ringset Included |
Yes |
| Second Compression Ring Thickness |
0.0600 |
| Make - Web |
Chevrolet |
| Wrist Pin Outer Diameter |
0.927 |
| Engine |
Small Block |
| Piston Series |
SRP Pro 4032 |
| Engine Type |
ICE |
| Title - Web |
SRP Pro 4032 Chevrolet Small Block Piston Kit - 4.020 in. Bore - 1.560 in. CH, -24.00 CC |
| Piston Head Type |
Dish |
| Piston Pin Material |
5115 |
| Forging Type |
FSR |
| Wrist Pin Wall Thickness |
0.150 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
12.0000 |
