As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan VQ35HR |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.780 Bore, 1.198 CD, 0.866 Pin, Set of 6. |
| Description_EXT |
JE, Nissan, VQ35HR, 3.779 in. Bore, 10.00:1, Dome, 6 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Nissan VQ35HR, 96.00 Bore, Dome, Set of 6 |
| Make |
NISSAN |
| Product Market |
Sport Compact |
| Bore Diameter |
96.00 |
| Top Compression Ring Thickness |
0.0400 |
| Compression Height |
1.198 |
| Piston Quantity |
6 |
| Cylinder Head |
VQ35HR |
| Piston Average Weight |
398 |
| Piston Pin Outside Diameter |
0.866 |
| Piston Pin Wall Thickness |
0.150 |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.866 |
| Piston Material |
2618 |
| Product Type |
Engine Piston Kit |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Title |
JE Pistons - Nissan, VQ35HR, 96.00 mm Bore, Piston Kit |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Engine - Web |
VQ35HR |
| Add-On |
866-2250-15-51C |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 (C, R or CR) |
CR |
| Engine |
VQ35HR |
| Prop 65 Yes/No |
Yes |
| Industry |
Automotive |
| Add-On |
866-063-MW |
| Piston Volume |
-0.60 |
| Add-On |
JG1001-3780 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Nissan |
| Title - Web |
JE Pistons Nissan VQ35HR Piston Kit - 96.00 mm Bore - 1.198 in. CH, -0.60 CC |
| Piston Series |
JE Pistons |
| Piston Head Type |
Dome |
| Ringset Included |
Yes |
| Piston Pin Material |
5115 |
| Piston Pin Length |
2.250 |
| Oil Ring Thickness |
0.111 |
| Engine Type |
ICE |
| Out of Stock Message |
Call for Availability |
| Forging Type |
FSR |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
5.0000 |
