As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Toyota 1FZ-FE Stroker |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.937 Bore, 1.535 CD, 1.024 Pin, Set of 6. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, Toyota, 1FZ-FE, 3.937 in. Bore, 8.50:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Toyota 1FZ-FE, 100.00 Bore, Dish, Set of 6 |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Piston Pin Material |
5115 |
| Piston Material |
2618 |
| Piston Volume |
-17.10 |
| Engine - Web |
1FZ-FE |
| Forging Type |
Round |
| Oil Ring Thickness |
0.111 |
| Title |
JE Pistons - Toyota, 1FZ-FE, 100.00 mm Bore, Piston Kit |
| Piston Series |
JE Pistons |
| Ring Set Included |
Yes |
| Piston Pin Wall Thickness |
0.200 |
| Compression Height |
1.535 |
| Engine Type |
ICE |
| Piston Quantity |
6 |
| Piston Pin Outside Diameter |
1.024 |
| Prop 65 (C, R or CR) |
CR |
| Product Type |
Engine Piston Kit |
| Product Market |
Sport Compact |
| Wrist Pin Length |
2.500 |
| Wrist Pin Wall Thickness |
0.200 |
| Wrist Pin Outer Diameter |
1.024 |
| Out of Stock Message |
Call for Availability |
| Piston Average Weight |
459 |
| Title - Web |
JE Pistons Toyota 1FZ-FE Piston Kit - 100.00 mm Bore - 1.535 in. CH, -17.10 CC |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Add-On |
031-042-CS |
| Piston Pin Length |
2.500 |
| Add-On |
JG1001-3937 |
| Add-On |
024-2500-20-51S |
| Ringset Included |
Yes |
| Bore Diameter |
100.00 |
| Top Compression Ring Thickness |
0.0400 |
| Make |
TOYOTA |
| Cylinder Head |
1FZ-FE |
| Second Compression Ring Thickness |
0.0480 |
| Piston Head Type |
Dish |
| Engine |
1FZ-FE |
| Industry |
Automotive |
| Prop 65 Yes/No |
Yes |
| Make - Web |
Toyota |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
5.0000 |
