As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Subaru EJ205 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.622 Bore, 1.287 CD, 0.905 Pin, Set of 4. |
| Description_EXT |
JE, Subaru, EJ Series, 3.622 in. Bore, 8.50:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Subaru EJ205, 92.00 Bore, Dish, Set of 4 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Pin Material |
5115 |
| Engine |
EJ SERIES |
| Piston Head Type |
Dish |
| Piston Pin Length |
2.250 |
| Ringset Included |
Yes |
| Piston Series |
JE Pistons |
| Product Market |
Sport Compact |
| Make |
SUBARU |
| Piston Pin Wall Thickness |
0.180 |
| Top Compression Ring Thickness |
0.0400 |
| Oil Ring Thickness |
0.111 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Engine Type |
ICE |
| Forging Type |
FSR |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Outer Diameter |
0.905 |
| Add-On |
905-2250-18-51S |
| Piston Volume |
-11.00 |
| Piston Quantity |
4 |
| Product Type |
Engine Piston Kit |
| Out of Stock Message |
Call for Availability |
| Piston Pin Outside Diameter |
0.905 |
| Cylinder Head |
EJ205 WRX |
| Title - Web |
JE Pistons Subaru EJ Series Piston Kit - 92.00 mm Bore - 1.287 in. CH, -11.00 CC |
| Prop 65 Yes/No |
Yes |
| Title |
JE Pistons - Subaru, EJ Series, 92.00 mm Bore, Piston Kit |
| Piston Average Weight |
359 |
| Compression Height |
1.287 |
| Add-On |
JG1001-3622 |
| Second Compression Ring Thickness |
0.0480 |
| Bore Diameter |
92.00 |
| Industry |
Automotive |
| Piston Material |
2618 |
| Add-On |
905-042-CT |
| Prop 65 (C, R or CR) |
CR |
| Wrist Pin Length |
2.250 |
| Engine - Web |
EJ Series |
| Make - Web |
Subaru |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
Yes |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
