As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Audi 1.8T 20V |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.268 Bore, 1.286 CD, 0.787 Pin, Set of 4. |
| Description_EXT |
JE, Audi/VW, 1.8T 20V, 3.268 in. Bore, 8.50:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Audi 1.8T, 83.00 Bore, Dish, Set of 4 |
| Engine - Web |
1.8T 20V |
| Piston Pin Wall Thickness |
0.180 |
| Piston Head Type |
Dish |
| Title |
JE Pistons - Audi, 1.8T 20V, 83.00 mm Bore, Piston Kit |
| Oil Ring Thickness |
0.111 |
| Ringset Included |
Yes |
| Engine Type |
ICE |
| Compression Height |
1.286 |
| Top Compression Ring Thickness |
0.0400 |
| Piston Series |
JE Pistons |
| Engine |
1.8T 20V |
| Piston Pin Material |
5115 |
| Make |
AUDI |
| Piston Pin Outside Diameter |
0.787 |
| Title - Web |
JE Pistons Audi 1.8T 20V Piston Kit - 83.00 mm Bore - 1.286 in. CH, -12.90 CC |
| Forging Type |
Round |
| Product Market |
European |
| Bore Diameter |
83.00 |
| Wrist Pin Outer Diameter |
0.787 |
| Wrist Pin Wall Thickness |
0.180 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Piston Material |
2618 |
| Out of Stock Message |
Call for Availability |
| Second Compression Ring Thickness |
0.0480 |
| Product Type |
Engine Piston Kit |
| Prop 65 Yes/No |
Yes |
| Add-On |
787-2250-18-51C |
| Industry |
Automotive |
| Add-On |
JG1001-3268 |
| Cylinder Head |
1.8T APH |
| Piston Quantity |
4 |
| Piston Average Weight |
310 |
| Add-On |
787-050-MW |
| Piston Volume |
-12.90 |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Length |
2.250 |
| Make - Web |
Audi |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Length |
2.250 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
