As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 2.0T FSI 04-08 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.287 Bore, 1.165 CD, 0.787 Pin, Set of 4. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, VW, 2.0T FSI - 04-08 - 20mm Pin, 3.287 in. Bore, 8.50:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Volkswagen 2.0L Turbo, 83.50 Bore, Dish, Set of 4 |
| Ring Set Included |
Yes |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Quantity |
4 |
| Piston Volume |
-12.90 |
| Engine Detail |
2.0T FSI 04-08 20 mm Pin |
| Product Type |
Engine Piston Kit |
| Industry |
Automotive |
| Piston Material |
2618 |
| Cylinder Head |
2.0LGOLF FSI |
| Piston Average Weight |
298 |
| Prop 65 (C, R or CR) |
CR |
| Wrist Pin Length |
2.250 |
| Second Compression Ring Thickness |
0.0480 |
| Add-On |
787-2250-18-51C |
| Title - Web |
JE Pistons Volkswagen 2.0T FSI Piston Kit - 83.50 mm Bore - 1.165 in. CH, -12.90 CC |
| Piston Pin Length |
2.250 |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Add-On |
JG1001-3287 |
| Ringset Included |
Yes |
| Add-On |
787-050-MW |
| Make - Web |
Volkswagen |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Top Compression Ring Thickness |
0.0400 |
| Oil Ring Thickness |
0.111 |
| Forging Type |
Round |
| Compression Height |
1.165 |
| Engine Type |
ICE |
| Title |
JE Pistons - Volkswagen, 2.0T FSI, 83.50 mm Bore, Piston Kit |
| Product Market |
European |
| Piston Pin Material |
5115 |
| Piston Head Type |
Dish |
| Piston Pin Wall Thickness |
0.180 |
| Piston Series |
JE Pistons |
| Engine |
2.0T FSI 04-08 20 mm Pin |
| Bore Diameter |
83.50 |
| Piston Pin Outside Diameter |
0.787 |
| Make |
VOLKSWAGEN |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Outer Diameter |
0.787 |
| Engine - Web |
2.0T FSI |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
7.0000 |
