SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 351W Windsor |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.030 Bore, 1.230 CD, 0.927 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_EXT |
SRP Pro 4032, Ford, Small Block Ford, 4.030 in. Bore, 1.230 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_INV |
SRP Pro, Piston Set |
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford 351 Windsor, 4.030 Bore, Flat, Set of 8 |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Add-On |
927-2250-15-51C |
| Add-On |
JG31F1-4030-2 |
| Add-On |
927-073-MW |
| Title - Web |
SRP Pro 4032 Ford Small Block Piston Kit - 4.030 in. Bore - 1.230 in. CH, -5.00 CC |
| Out of Stock Message |
Call for Availability |
| Piston Pin Length |
2.250 |
| Piston Head Type |
Flat |
| Prop 65 Yes/No |
Yes |
| Engine Type |
ICE |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Series |
SRP Pro 4032 |
| Engine |
Small Block |
| Ringset Included |
Yes |
| Piston Pin Wall Thickness |
0.150 |
| Second Compression Ring Thickness |
0.0600 |
| Piston Pin Outside Diameter |
0.927 |
| Wrist Pin Outer Diameter |
0.927 |
| Make - Web |
Ford |
| Engine - Web |
Small Block |
| Compression Height |
1.230 |
| Industry |
Automotive |
| Oil Ring Thickness |
0.119 |
| Cylinder Head |
SMALL BLOCK FORD 20 DEG |
| Piston Material |
4032 |
| Title |
SRP Pro 4032 - Ford, Small Block, 4.030 in. Bore, Piston Kit |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Bore Diameter |
4.030 |
| Piston Average Weight |
417 |
| Piston Volume |
-5.00 |
| Piston Pin Material |
5115 |
| Top Compression Ring Thickness |
0.0480 |
| Product Market |
Domestic |
| Product Type |
Engine Piston Kit |
| Forging Type |
FSR |
| Prop 65 (C, R or CR) |
CR |
| Make |
FORD |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
