As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Volkswagen 3.2L VR6 R32 24V |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 3.307 Bore, 1.592 CD, 0.787 Pin, Set of 6. |
| Description_EXT |
JE, VW, 3.2L VR6 24V, 3.307 in. Bore, 8.50:1, Flat Top, 6 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Volkswagen 3.2L R32 24V VR6, 84.00 Bore, Flat, Set of 6 |
| Top Compression Ring Thickness |
0.0400 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Product Market |
European |
| Piston Average Weight |
330 |
| Bore Diameter |
84.00 |
| Piston Pin Outside Diameter |
0.787 |
| Compression Height |
1.592 |
| Piston Pin Wall Thickness |
0.180 |
| Engine - Web |
3.2L VR6 24V |
| Wrist Pin Wall Thickness |
0.180 |
| Piston Quantity |
6 |
| Title |
JE Pistons - Volkswagen, 3.2L VR6 24V, 84.00 mm Bore, Piston Kit |
| Make |
VOLKSWAGEN |
| Piston Material |
2618 |
| Cylinder Head |
R32 VR6 |
| Ring Set Included |
Yes |
| Wrist Pin Outer Diameter |
0.787 |
| Piston Volume |
-27.00 |
| Prop 65 Yes/No |
Yes |
| Add-On |
JG1001-3307 |
| Product Type |
Engine Piston Kit |
| Add-On |
787-2250-18-51C |
| Industry |
Automotive |
| Prop 65 (C, R or CR) |
CR |
| Out of Stock Message |
Call for Availability |
| Add-On |
787-050-MW |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Length |
2.250 |
| Engine |
3.2L VR6 24V |
| Engine Type |
ICE |
| Title - Web |
JE Pistons Volkswagen 3.2L VR6 24V Piston Kit - 84.00 mm Bore - 1.592 in. CH, -27.00 CC |
| Piston Pin Material |
5115 |
| Piston Pin Length |
2.250 |
| Piston Head Type |
Flat |
| Second Compression Ring Thickness |
0.0480 |
| Ringset Included |
Yes |
| Oil Ring Thickness |
0.111 |
| Forging Type |
Round |
| Piston Series |
JE Pistons |
| Make - Web |
Volkswagen |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
7.0000 |
