Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford 428 FE |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.155 Bore, 1.325 CD, 0.990 Pin, Set of 8. |
| Description_EXT |
SRP, Ford, Big Block Ford FE, 4.155 in. Bore, 1.325 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_TLE |
Ford 428 FE, 4.155 Bore, Flat, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Oil Ring Thickness |
0.188 |
| Make |
FORD |
| Title |
SRP - Ford, Big Block FE, 4.155 in. Bore, Piston Kit |
| Piston Pin Material |
5115 |
| Product Market |
Domestic |
| Product Type |
Engine Piston Kit |
| Compression Height |
1.325 |
| Piston Volume |
72.00 |
| Forging Type |
FSR |
| Piston Material |
4032 |
| Top Compression Ring Thickness |
0.0640 |
| Engine Type |
ICE |
| Piston Series |
SRP |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Pin Wall Thickness |
0.150 |
| Engine - Web |
Big Block FE |
| Wrist Pin Outer Diameter |
0.990 |
| Wrist Pin Length |
2.750 |
| Ring Set Included |
No |
| Wrist Pin Wall Thickness |
0.150 |
| Out of Stock Message |
Call for Availability |
| Engine |
Big Block FE |
| Piston Head Type |
Flat |
| Ringset Included |
No |
| Add-On |
990-042-CS |
| Title - Web |
SRP Ford Big Block FE Piston Kit - 4.155 in. Bore - 1.325 in. CH, 72.00 CC |
| Second Compression Ring Thickness |
0.0640 |
| Piston Pin Length |
2.750 |
| Add-On |
S100S8-4155-5 |
| Industry |
Automotive |
| Bore Diameter |
4.155 |
| Piston Pin Outside Diameter |
0.990 |
| Cylinder Head |
EDEL 6005/06 |
| Add-On |
990-2750-15-51S |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 Yes/No |
Yes |
| Piston Average Weight |
479 |
| Make - Web |
Ford |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
