Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
SRP, Chevrolet, Small Block Chevrolet, 4.040 in. Bore, 1.560 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 4.040 Bore, 1.560 CD, 0.927 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_TLE |
Chevrolet 350, 4.040 Bore, Flat, Set of 8 |
| Wrist Pin Length |
2.500 |
| Prop 65 Yes/No |
Yes |
| Product Type |
Engine Piston Kit |
| Ring Set Included |
No |
| Second Compression Ring Thickness |
0.0640 |
| Cylinder Head |
4-VALVE |
| Title - Web |
SRP Chevrolet Small Block Piston Kit - 4.040 in. Bore - 1.560 in. CH, -5.00 CC |
| Prop 65 (C, R or CR) |
CR |
| Piston Volume |
-5.00 |
| Piston Material |
2618 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Chevrolet |
| Top Compression Ring Thickness |
0.0640 |
| Bore Diameter |
4.040 |
| Compression Height |
1.560 |
| Add-On |
S100S8-4040-5 |
| Add-On |
927-042-CS |
| Out of Stock Message |
Call for Availability |
| Industry |
Automotive |
| Piston Pin Length |
2.500 |
| Forging Type |
FSR |
| Product Market |
Domestic |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Add-On |
927-2500-13-51S |
| Piston Average Weight |
459 |
| Title |
SRP - Chevrolet, Small Block, 4.040 in. Bore, Piston Kit |
| Engine Type |
ICE |
| Piston Head Type |
Flat |
| Ringset Included |
No |
| Engine |
Small Block |
| Wrist Pin Wall Thickness |
0.130 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Pin Wall Thickness |
0.130 |
| Make |
CHEVROLET |
| Piston Series |
SRP |
| Oil Ring Thickness |
0.188 |
| Piston Pin Material |
5115 |
| Piston Pin Outside Diameter |
0.927 |
| Engine - Web |
Small Block |
| Wrist Pin Outer Diameter |
0.927 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
12.0000 |
