As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Lamborghini 5.0L V10 Gallardo |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.248 Bore, 1.086 CD, 0.787 Pin, Set of 10. |
| Description_EXT |
JE, Lamborghini, 5.0L V10 Gallardo, 3.248 in. Bore, 9.00:1, Inverted Dome/Dish, 1 Cyl. Piston Kit |
| Description_SHO |
Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_TLE |
Lamborghini 5.0L V10, 82.50 Bore, Dish, Set of 10 |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Piston Pin Length |
2.250 |
| Make - Web |
Lamborghini |
| Oil Ring Thickness |
0.111 |
| Engine |
5.0L V10 GALLARDO |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ringset Included |
Yes |
| Engine Type |
ICE |
| Piston Pin Material |
9310 |
| Piston Head Type |
Dish |
| Forging Type |
FSR |
| Make |
LAMBORGHINI |
| Piston Pin Wall Thickness |
0.210 |
| Wrist Pin Outer Diameter |
0.787 |
| Piston Pin Outside Diameter |
0.787 |
| Piston Series |
JE Pistons |
| Compression Height |
1.086 |
| Add-On |
787-050-MW |
| Piston Quantity |
0 |
| Industry |
Automotive |
| Product Type |
Engine Piston Kit |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Add-On |
XC8255 |
| Piston Average Weight |
271 |
| Title |
JE Pistons - Lamborghin.i, 5.0L V10 Gallardo, 82.50 mm Bore, Piston Kit |
| Bore Diameter |
82.50 |
| Piston Volume |
-11.20 |
| Product Market |
European |
| Second Compression Ring Thickness |
0.0480 |
| Title - Web |
JE Pistons Lamborghin.i 5.0L V10 Gallardo Piston Kit - 82.50 mm Bore - 1.086 in. CH, -11.20 CC |
| Out of Stock Message |
Call for Availability |
| Piston Material |
2618 |
| Top Compression Ring Thickness |
0.0400 |
| Add-On |
787-2250-21-93C |
| Wrist Pin Length |
2.250 |
| Engine - Web |
5.0L V10 Gallardo |
| Ring Set Included |
Yes |
| Wrist Pin Wall Thickness |
0.210 |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Cylinder Head |
5.0L V10 |
| Wrist Pin Material |
9310 Nickel Carbon Steel Alloy |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
11.0000 |
