The Edelbrock #60779 Performer RPM head is designed for use with non-emission 1968-91 Chrysler 318-340-360 c.i.d. engine applications. The Edelbrock #60779 Performer RPM head is perfect for street performance, daily drivers, street rods and muscle cars where seat-of-the-pants performance is needed. This cylinder head delivers great throttle response and power from 1500 to 6500 rpm. They also feature the highest quality intake and exhaust valves and valve springs. For use on pre-pollution controlled vehicles only.
Specifications:
| Description_ABR |
Cyl. Head |
| Description_ASM |
Chrysler:Small-Block:273 (4.5L)/318 (5.2L)/340 (5.6L)/360 (5.9L) |
| Description_DEF |
Engine Cylinder Head |
| Description_EXT |
The Edelbrock #60779 Performer RPM heads are designed for use with non-emission 1968-91 Chrysler 318-340-360 engines. The #60779 heads are perfect for street performance, daily drivers and muscle cars where more performance is needed. |
| Description_INV |
Edelbrock SB Chrysler Cylinder Head |
| Description_LAB |
RPM Small-Block Chrysler LA Cylinder Head Hydraulic Flat Tappet Cam |
| Description_MKT |
The Edelbrock #60779 Performer RPM head is designed for use with non-emission 1968-91 Chrysler 318-340-360 c.i.d. engine applications. The Edelbrock #60779 Performer RPM head is perfect for street performance, daily drivers, street rods and muscle cars where seat-of-the-pants performance is needed. This cylinder head delivers great throttle response and power from 1500 to 6500 rpm. They also feature the highest quality intake and exhaust valves and valve springs. For use on pre-pollution controlled vehicles only. |
| Description_TRA |
EQUIPPED WITH SPRINGS FOR USE IN HYDRAULIC FLAT TAPPET CAMSHAFT APPLICATIONS |
| Description_TRA |
Delivers outstanding performance in non-emission 1967-91 Chrysler 318-340-360 c.i.d. engines |
| Description_TRA |
Make 417 horsepower and 397 ft-lbs. of torque on pump gas with an Edelbrock Performer RPM intake manifold and matching camshaft |
| Description_TRA |
The special valvetrain in the 1970 340 T/A is not compatible with these cylinder heads. Match with Edelbrock head gasket sets. |
| Description_TRA |
Recommended spark plugs are Champion RC12YC or equivalent 14mm x 3/4" reach with flat gasket seat. |
| Description_TRA |
Deck thickness: 5/8" |
| Description_TRA |
Pushrod diameter: 5/16" |
| Retainer Included |
Yes |
| Horsepower |
350-450 |
| Valve Spring Diameter |
1.46 |
| Combustion Chamber Volume |
63 |
| EGR Port |
No |
| Head Casting Number |
N/A |
| Exhaust Port Location |
Standard |
| CNC Ported |
No |
| Intake Valve Diameter |
2.02 |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Guide Plates Included |
No |
| Seat Material |
Ductile Iron |
| Seat Angle |
Exhaust 45 deg/Intake 45 |
| Camshaft Type |
Flat Tappet |
| Valve Included |
Yes |
| Valve Springs Included |
Yes |
| Grade Type |
Performance |
| Construction Type |
Complete |
| Valve Stem Diameter |
0.3438 |
| Valve Angle |
18 |
| Valve Spring Maximum Lift |
0.575 |
| Series |
Performer RPM |
| Family |
Performer RPM |
| Guide Material |
Manganese Bronze |
| Exhaust Valve Diameter |
1.60 |
| Quantity |
Sold Individually |
| Intake Runner Volume |
171 |
| Guide Plate Material |
Hardened Steel |
| Deck Thickness |
0.625 |
| Exhaust Runner Volume |
77 |
| Material |
Aluminum |
| Length |
9.0000 |
| Width |
11.0000 |
| Height |
26.0000 |
| Weight |
32.0000 |
