As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ferrari 2.9L 308 V8 4V |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.209 Bore, 1.209 CD, 0.728 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Ferrari, 2.9L 308 V8 4V, 3.209 in. Bore, 9.50:1, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_TLE |
Ferrari 2.9L 308 V8 2V, 81.50 Bore, Dish, Set of 8 |
| Description_SHO |
Piston Kit |
| Piston Head Type |
Dish |
| Piston Pin Outside Diameter |
0.728 |
| Piston Pin Length |
2.250 |
| Product Market |
European |
| Piston Series |
JE Pistons |
| Wrist Pin Outer Diameter |
0.728 |
| Make |
FERRARI |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Compression Height |
1.209 |
| Engine |
2.9L 308 V8 4V |
| Piston Material |
2618 |
| Piston Pin Wall Thickness |
0.120 |
| Out of Stock Message |
Call for Availability |
| Forging Type |
Round |
| Ringset Included |
Yes |
| Oil Ring Thickness |
0.111 |
| Engine Type |
ICE |
| Bore Diameter |
81.50 |
| Title |
JE Pistons - Ferrari, 2.9L 308 V8 4V, 81.50 mm Bore, Piston Kit |
| Wrist Pin Wall Thickness |
0.120 |
| Engine - Web |
2.9L 308 V8 4V |
| Second Compression Ring Thickness |
0.0480 |
| Industry |
Automotive |
| Cylinder Head |
308 QUATTROVALVOLE V8 |
| Piston Quantity |
8 |
| Piston Volume |
-12.00 |
| Prop 65 (C, R or CR) |
CR |
| Add-On |
728-2250-12-TSC |
| Title - Web |
JE Pistons Ferrari 2.9L 308 V8 4V Piston Kit - 81.50 mm Bore - 1.209 in. CH, -12.00 CC |
| Add-On |
728-050-MW |
| Add-On |
JG1001-3209 |
| Prop 65 Yes/No |
Yes |
| Top Compression Ring Thickness |
0.0400 |
| Product Type |
Engine Piston Kit |
| Ring Set Included |
Yes |
| Make - Web |
Ferrari |
| Wrist Pin Length |
2.250 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
9.0000 |
