As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan RB25DET |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Nissan, RB Series, 3.396 in. Bore, 8.50:1, Dome, 6 Cyl. Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.396 Bore, 1.220 CD, 0.827 Pin, Set of 6. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Nissan RB25DET, 86.25 Bore, Dome, Set of 6 |
| Title |
JE Pistons - Nissan, RB Series, 86.25 mm Bore, Piston Kit |
| Bore Diameter |
86.25 |
| Piston Pin Wall Thickness |
0.150 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Wrist Pin Outer Diameter |
0.827 |
| Top Compression Ring Thickness |
0.0400 |
| Product Type |
Engine Piston Kit |
| Piston Series |
JE Pistons |
| Oil Ring Thickness |
0.111 |
| Make |
NISSAN |
| Piston Quantity |
6 |
| Piston Pin Material |
5115 |
| Piston Volume |
15.30 |
| Product Market |
Sport Compact |
| Ring Set Included |
Yes |
| Wrist Pin Length |
2.250 |
| Add-On |
827-063-MW |
| Compression Height |
1.220 |
| Piston Pin Outside Diameter |
0.827 |
| Industry |
Automotive |
| Add-On |
827-2250-15-51C |
| Cylinder Head |
4-VALVE |
| Engine Type |
ICE |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Add-On |
JG1001-3396 |
| Forging Type |
FSR |
| Piston Head Type |
Dome |
| Engine - Web |
RB Series |
| Wrist Pin Wall Thickness |
0.150 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Nissan |
| Second Compression Ring Thickness |
0.0480 |
| Title - Web |
JE Pistons Nissan RB Series Piston Kit - 86.25 mm Bore - 1.220 in. CH, 15.30 CC |
| Piston Material |
2618 |
| Engine |
RB SERIES |
| Ringset Included |
Yes |
| Piston Pin Length |
2.250 |
| Prop 65 (C, R or CR) |
CR |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
5.0000 |
