As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Honda L15B7 Turbo |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 2.874 Bore, 1.126 CD, 0.787 Pin, Set of 4. |
| Description_EXT |
JE, Honda, L15B7 Turbo, 2.874 in. Bore, 10.30:1, Inverted Dome/Dish, 4 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_TLE |
Honda L15B7, 73.00 Bore, Dish, Set of 4 |
| Piston Pin Wall Thickness |
0.180 |
| Piston Volume |
-9.60 |
| Engine - Web |
L15B7 Turbo |
| Piston Quantity |
4 |
| Piston Material |
2618 |
| Top Compression Ring Thickness |
0.0400 |
| Title |
JE Pistons - Honda, L15B7 Turbo, 73.00 mm Bore, Piston Kit |
| Bore Diameter |
73.00 |
| Piston Average Weight |
218 |
| Cylinder Head |
L15A |
| Compression Height |
1.126 |
| Add-On |
787-2250-18-51C |
| Piston Pin Outside Diameter |
0.787 |
| Add-On |
787-050-MW |
| Product Market |
Sport Compact |
| Add-On |
JG1001-2874 |
| Piston Pin Material |
5115 |
| Prop 65 (C, R or CR) |
CR |
| Ring Set Included |
Yes |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Outer Diameter |
0.787 |
| Make |
HONDA |
| Industry |
Automotive |
| Prop 65 Yes/No |
Yes |
| Ringset Included |
Yes |
| Second Compression Ring Thickness |
0.0480 |
| Product Type |
Engine Piston Kit |
| Title - Web |
JE Pistons Honda L15B7 Turbo Piston Kit - 73.00 mm Bore - 1.126 in. CH, -9.60 CC |
| Out of Stock Message |
Call for Availability |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Length |
2.250 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Make - Web |
Honda |
| Engine Type |
ICE |
| Piston Series |
JE Pistons |
| Engine |
L15B7 TURBO |
| Oil Ring Thickness |
0.111 |
| Piston Head Type |
Dish |
| Forging Type |
Round |
| Piston Pin Length |
2.250 |
| Length |
5.0000 |
| Width |
9.0000 |
| Height |
5.0000 |
| Weight |
5.0000 |
