As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Ford 3.5L Ecoboost Gen II V6 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.642 Bore, 1.240 CD, 0.905 Pin, Set of 6. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Ford, 3.5L EcoBoost Gen 2 V6, 3.652 in. Bore, 10.00:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford 3.5L Eco Boost V6, 92.50 Bore, Dish, Set of 6 |
| Compression Height |
1.240 |
| Ringset Included |
Yes |
| Engine - Web |
3.5L EcoBoost Gen 2 V6 |
| Oil Ring Thickness |
0.111 |
| Piston Head Type |
Dish |
| Forging Type |
FSR |
| Piston Pin Wall Thickness |
0.180 |
| Piston Pin Length |
2.250 |
| Engine |
3.5L ECOBOOST GEN 2 V6 |
| Title |
JE Pistons - Ford, 3.5L EcoBoost Gen 2 V6, 92.50 mm Bore, Piston Kit |
| Out of Stock Message |
Call for Availability |
| Make |
FORD |
| Product Market |
Sport Compact |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Title - Web |
JE Pistons Ford 3.5L EcoBoost Gen 2 V6 Piston Kit - 92.50 mm Bore - 1.240 in. CH, -12.50 CC |
| Prop 65 Yes/No |
Yes |
| Piston Volume |
-12.50 |
| Top Compression Ring Thickness |
0.0400 |
| Piston Average Weight |
385 |
| Bore Diameter |
92.50 |
| Piston Series |
JE Pistons |
| Engine Type |
ICE |
| Piston Pin Outside Diameter |
0.905 |
| Piston Pin Material |
5115 |
| Ring Set Included |
Yes |
| Wrist Pin Wall Thickness |
0.180 |
| Wrist Pin Outer Diameter |
0.905 |
| Wrist Pin Length |
2.250 |
| Industry |
Automotive |
| Piston Material |
2618 |
| Piston Quantity |
6 |
| Add-On |
905-2250-18-51C |
| Add-On |
905-073-MW |
| Add-On |
JG1001-3642 |
| Cylinder Head |
ECOBOOST V6 |
| Second Compression Ring Thickness |
0.0480 |
| Prop 65 (C, R or CR) |
CR |
| Product Type |
Engine Piston Kit |
| Make - Web |
Ford |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
8.0000 |
