As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Porsche 2.7L 911 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.661 Bore, 1.335 CD, 0.866 Pin, Set of 6. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Porsche, Aircooled - 6 Cyl, 3.661 in. Bore, 9.50:1, Dome, 6 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Porsche 2.7L, 93.00 Bore, Dome, Set of 6 |
| Wrist Pin Wall Thickness |
0.150 |
| Engine |
2.7L Aircooled |
| Piston Head Type |
Dome |
| Title - Web |
JE Pistons Porsche 2.7L Aircooled Piston Kit - 93.00 mm Bore - 1.335 in. CH, 18.60 CC |
| Forging Type |
Round |
| Piston Pin Length |
2.500 |
| Piston Pin Material |
9310 |
| Engine Type |
ICE |
| Ringset Included |
Yes |
| Make |
PORSCHE |
| Piston Series |
JE Pistons |
| Piston Pin Wall Thickness |
0.150 |
| Oil Ring Thickness |
0.111 |
| Make - Web |
Porsche |
| Wrist Pin Outer Diameter |
0.866 |
| Prop 65 Yes/No |
Yes |
| Compression Height |
1.335 |
| Product Market |
European |
| Piston Material |
2618 |
| Add-On |
866-2500-15-93C |
| Piston Volume |
18.60 |
| Piston Quantity |
6 |
| Second Compression Ring Thickness |
0.0480 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Piston Pin Outside Diameter |
0.866 |
| Add-On |
JG1001-3661 |
| Add-On |
866-063-MW |
| Top Compression Ring Thickness |
0.0400 |
| Product Type |
Engine Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Out of Stock Message |
Call for Availability |
| Ring Set Included |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
9310 Nickel Carbon Steel Alloy |
| Engine - Web |
2.7L Aircooled |
| Wrist Pin Length |
2.500 |
| Title |
JE Pistons - Porsche, 2.7L Aircooled, 93.00 mm Bore, Piston Kit |
| Cylinder Head |
2.7 Liter |
| Bore Diameter |
93.00 |
| Industry |
Automotive |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
8.0000 |
