As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Porsche 2.4L |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Dome, 3.346 Bore, 1.335 CD, 0.866 Pin, Set of 6. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, Porsche, Aircooled - 6 Cyl, 3.346 in. Bore, 9.50:1, Dome, 6 Cyl. Piston Kit |
| Description_INV |
JE Pistons, Piston Kit |
| Description_TLE |
Porsche 2.4L, 85.00 Bore, Dome, Set of 6 |
| Description_SHO |
Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Engine Type |
ICE |
| Engine |
2.4L Aircooled |
| Piston Head Type |
Dome |
| Piston Pin Material |
9310 |
| Ringset Included |
Yes |
| Top Compression Ring Thickness |
0.0400 |
| Piston Pin Wall Thickness |
0.150 |
| Compression Height |
1.335 |
| Product Market |
European |
| Piston Series |
JE Pistons |
| Make |
PORSCHE |
| Title |
JE Pistons - Porsche, 2.4L Aircooled, 85.00 mm Bore, Piston Kit |
| Engine - Web |
2.4L Aircooled |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.150 |
| Bore Diameter |
85.00 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>European |
| Cylinder Head |
2 VALVE |
| Piston Pin Length |
2.500 |
| Add-On |
866-2500-15-93C |
| Title - Web |
JE Pistons Porsche 2.4L Aircooled Piston Kit - 85.00 mm Bore - 1.335 in. CH, 26.80 CC |
| Product Type |
Engine Piston Kit |
| Piston Volume |
26.80 |
| Add-On |
JG1001-3346 |
| Industry |
Automotive |
| Oil Ring Thickness |
0.111 |
| Second Compression Ring Thickness |
0.0480 |
| Piston Pin Outside Diameter |
0.866 |
| Piston Quantity |
6 |
| Piston Material |
2618 |
| Out of Stock Message |
Call for Availability |
| Add-On |
866-063-MW |
| Forging Type |
Round |
| Prop 65 Yes/No |
Yes |
| Prop 65 (C, R or CR) |
CR |
| Ring Set Included |
Yes |
| Wrist Pin Material |
9310 Nickel Carbon Steel Alloy |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Porsche |
| Wrist Pin Length |
2.500 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
8.0000 |
