JE Pistons 345870 Piston Set, 2618, Dome, 3.701 Bore, 1.161 CD, 0.827 Pin, Set of 8.
2
sold in last
8
hours
$1,776.63
Guaranteed Fitment
Always the correct part
Added Value
Performance matched parts
In-House Experts
We know our products
Nationwide Delivery
Economy shipping
JE Pistons
ds_BHXG_345870
Engine Piston Kit
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
Description_ASM | Ford 5.2L Modular GT350 Voodoo |
Description_DEF | Engine Piston Kit |
Description_DES | Piston Set, 2618, Dome, 3.701 Bore, 1.161 CD, 0.827 Pin, Set of 8. |
Description_INV | JE Pistons, Piston Kit |
Description_EXT | JE, Ford, Modular Ford, 3.701 in. Bore, 1.161 CD, Dome, 8 Cyl. Piston Kit |
Description_FAB |
|
Description_TLE | Ford 5.2L VooDoo, 3.701 Bore, Dome, Set of 8 |
Description_SHO | Piston Kit |
Description_MKT | As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
Add-On | JG1001-3701 |
Add-On | 827-2250-15-51C |
Add-On | 827-063-MW |
Cylinder Head | MODULAR 5.2L VOODOO |
Industry | Automotive |
Title - Web | JE Pistons Ford Modular Piston Kit - 3.701 in. Bore - 1.161 in. CH, 6.70 CC |
Wrist Pin Material | 5115 Low Carbon Steel, Case Hardened |
Make - Web | Ford |
Prop 65 - Short Label | Prop 65 Warning Label.JPG |
Engine | Modular |
Out of Stock Message | Call for Availability |
Piston Head Type | Dome |
Make | FORD |
Category Hierarchy | Auto>JE Pistons>Piston Kits>Domestic |
Ringset Included | Yes |
Piston Average Weight | 392 |
Piston Pin Material | 5115 |
Compression Height | 1.161 |
Prop 65 Yes/No | Yes |
Piston Series | JE Pistons |
Forging Type | FSR |
Top Compression Ring Thickness | 0.0400 |
Piston Pin Outside Diameter | 0.827 |
Piston Pin Length | 2.250 |
Second Compression Ring Thickness | 0.0480 |
Prop 65 (C, R or CR) | CR |
Wrist Pin Length | 2.250 |
Wrist Pin Outer Diameter | 0.827 |
Ring Set Included | Yes |
Product Market | Domestic |
Piston Material | 2618 |
Title | JE Pistons - Ford, Modular, 3.701 in. Bore, Piston Kit |
Piston Quantity | 8 |
Piston Volume | 6.70 |
Piston Pin Wall Thickness | 0.150 |
Engine Type | ICE |
Oil Ring Thickness | 0.111 |
Product Type | Engine Piston Kit |
Bore Diameter | 3.701 |
Engine - Web | Modular |
Wrist Pin Wall Thickness | 0.150 |
Length | 6.0000 |
Width | 12.0000 |
Height | 12.0000 |
Weight | 12.0000 |
