Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Big Block 440 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.350 Bore, 1.865 CD, 0.990 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_EXT |
SRP, Chrysler, Big Block Chrysler, 4.350 in. Bore, 1.865 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Chrysler 440, 4.350 Bore, Dish, Set of 8 |
| Title - Web |
SRP Chrysler Big Block Piston Kit - 4.350 in. Bore - 1.865 in. CH, -24.00 CC |
| Out of Stock Message |
Call for Availability |
| Piston Head Type |
Dish |
| Cylinder Head |
440 WEDGE |
| Add-On |
990-042-CS |
| Prop 65 Yes/No |
Yes |
| Ringset Included |
No |
| Add-On |
S100S8-4350-5 |
| Add-On |
990-2930-18-51S |
| Piston Pin Length |
2.930 |
| Engine |
Big Block |
| Second Compression Ring Thickness |
0.0640 |
| Engine Type |
ICE |
| Oil Ring Thickness |
0.188 |
| Piston Series |
SRP |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chrysler |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Pin Wall Thickness |
0.180 |
| Make |
CHRYSLER |
| Piston Average Weight |
691 |
| Bore Diameter |
4.350 |
| Product Market |
Domestic |
| Piston Volume |
-24.00 |
| Compression Height |
1.865 |
| Industry |
Automotive |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Material |
5115 |
| Piston Pin Outside Diameter |
0.990 |
| Piston Material |
4032 |
| Forging Type |
FSR |
| Top Compression Ring Thickness |
0.0640 |
| Product Type |
Engine Piston Kit |
| Title |
SRP - Chrysler, Big Block, 4.350 in. Bore, Piston Kit |
| Ring Set Included |
No |
| Wrist Pin Length |
2.930 |
| Wrist Pin Outer Diameter |
0.990 |
| Engine - Web |
Big Block |
| Wrist Pin Wall Thickness |
0.180 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
17.0000 |
