Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Big Block 440 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.360 Bore, 1.865 CD, 0.990 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chrysler, Big Block Chrysler, 4.360 in. Bore, 1.865 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_TLE |
Chrysler 440, 4.360 Bore, Flat, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Prop 65 (C, R or CR) |
CR |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Add-On |
S100S8-4360-5 |
| Piston Volume |
-6.00 |
| Piston Material |
4032 |
| Add-On |
990-042-CS |
| Add-On |
990-2930-15-51S |
| Ring Set Included |
No |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Industry |
Automotive |
| Prop 65 Yes/No |
Yes |
| Cylinder Head |
440 WEDGE |
| Out of Stock Message |
Call for Availability |
| Piston Pin Length |
2.930 |
| Product Type |
Engine Piston Kit |
| Make - Web |
Chrysler |
| Second Compression Ring Thickness |
0.0640 |
| Oil Ring Thickness |
0.188 |
| Piston Pin Wall Thickness |
0.150 |
| Engine |
Big Block |
| Title |
SRP - Chrysler, Big Block, 4.360 in. Bore, Piston Kit |
| Engine Type |
ICE |
| Ringset Included |
No |
| Top Compression Ring Thickness |
0.0640 |
| Piston Pin Material |
5115 |
| Title - Web |
SRP Chrysler Big Block Piston Kit - 4.360 in. Bore - 1.865 in. CH, -6.00 CC |
| Forging Type |
FSR |
| Piston Series |
SRP |
| Piston Head Type |
Flat |
| Wrist Pin Outer Diameter |
0.990 |
| Wrist Pin Wall Thickness |
0.150 |
| Bore Diameter |
4.360 |
| Product Market |
Domestic |
| Piston Pin Outside Diameter |
0.990 |
| Compression Height |
1.865 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Make |
CHRYSLER |
| Wrist Pin Length |
2.930 |
| Engine - Web |
Big Block |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
17.0000 |
