Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 351C Cleveland |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.040 Bore, 1.200 CD, 0.927 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.040 in. Bore, 1.200 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_TLE |
Ford 351 Cleveland, 4.040 Bore, Dish, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Piston Pin Length |
2.750 |
| Piston Head Type |
Dish |
| Prop 65 Yes/No |
Yes |
| Out of Stock Message |
Call for Availability |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.040 in. Bore - 1.200 in. CH, -16.00 CC |
| Add-On |
927-2750-15-51S |
| Second Compression Ring Thickness |
0.0640 |
| Add-On |
927-042-CS |
| Piston Series |
SRP |
| Add-On |
S100S8-4040-5 |
| Engine |
Small Block |
| Engine Type |
ICE |
| Ringset Included |
No |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Ford |
| Oil Ring Thickness |
0.218 |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Outside Diameter |
0.927 |
| Piston Pin Wall Thickness |
0.150 |
| Forging Type |
FSR |
| Title |
SRP - Ford, Small Block, 4.040 in. Bore, Piston Kit |
| Product Market |
Domestic |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Make |
FORD |
| Product Type |
Engine Piston Kit |
| Piston Average Weight |
451 |
| Bore Diameter |
4.040 |
| Compression Height |
1.200 |
| Wrist Pin Outer Diameter |
0.927 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Engine - Web |
Small Block |
| Wrist Pin Length |
2.750 |
| Wrist Pin Wall Thickness |
0.150 |
| Top Compression Ring Thickness |
0.0640 |
| Industry |
Automotive |
| Cylinder Head |
CLEVELAND |
| Piston Pin Material |
5115 |
| Piston Volume |
-16.00 |
| Piston Material |
4032 |
| Ring Set Included |
No |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
