Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Small Block 360 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.070 Bore, 1.670 CD, 0.984 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chrysler, Small Block Chrysler, 4.070 in. Bore, 1.670 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chrysler 360, 4.070 Bore, Flat, Set of 8 |
| Industry |
Automotive |
| Out of Stock Message |
Call for Availability |
| Cylinder Head |
340 WEDGE |
| Add-On |
990-042-CS |
| Add-On |
J100F8-4070-5 |
| Add-On |
984-2750-15-51S |
| Piston Material |
4032 |
| Piston Volume |
-5.00 |
| Product Type |
Engine Piston Kit |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Prop 65 Yes/No |
Yes |
| Piston Pin Length |
2.750 |
| Prop 65 (C, R or CR) |
CR |
| Engine |
Small Block |
| Title - Web |
SRP Chrysler Small Block Piston Kit - 4.070 in. Bore - 1.670 in. CH, -5.00 CC |
| Second Compression Ring Thickness |
0.0640 |
| Title |
SRP - Chrysler, Small Block, 4.070 in. Bore, Piston Kit |
| Piston Series |
SRP |
| Piston Pin Outside Diameter |
0.984 |
| Oil Ring Thickness |
0.188 |
| Engine Type |
ICE |
| Ringset Included |
No |
| Forging Type |
FSR |
| Wrist Pin Outer Diameter |
0.984 |
| Make - Web |
Chrysler |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Pin Material |
5115 |
| Piston Head Type |
Flat |
| Make |
CHRYSLER |
| Product Market |
Domestic |
| Compression Height |
1.670 |
| Top Compression Ring Thickness |
0.0640 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Pin Wall Thickness |
0.150 |
| Bore Diameter |
4.070 |
| Engine - Web |
Small Block |
| Wrist Pin Length |
2.750 |
| Ring Set Included |
No |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
