Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Small Block 340 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.040 Bore, 1.804 CD, 0.984 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_EXT |
SRP, Chrysler, Small Block Chrysler, 4.040 in. Bore, 1.804 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_TLE |
Chrysler 340, 4.040 Bore, Flat, Set of 8 |
| Description_SHO |
Piston Kit |
| Engine - Web |
Small Block |
| Piston Pin Wall Thickness |
0.150 |
| Make |
CHRYSLER |
| Piston Pin Outside Diameter |
0.984 |
| Prop 65 Yes/No |
Yes |
| Wrist Pin Length |
2.750 |
| Compression Height |
1.804 |
| Prop 65 (C, R or CR) |
CR |
| Wrist Pin Outer Diameter |
0.984 |
| Add-On |
984-2750-15-51S |
| Product Market |
Domestic |
| Bore Diameter |
4.040 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Engine |
Small Block |
| Piston Average Weight |
525 |
| Add-On |
990-042-CS |
| Product Type |
Engine Piston Kit |
| Industry |
Automotive |
| Piston Material |
4032 |
| Cylinder Head |
340 WEDGE |
| Out of Stock Message |
Call for Availability |
| Top Compression Ring Thickness |
0.0640 |
| Piston Volume |
-5.00 |
| Title |
SRP - Chrysler, Small Block, 4.040 in. Bore, Piston Kit |
| Add-On |
S100S8-4040-5 |
| Wrist Pin Wall Thickness |
0.150 |
| Ring Set Included |
No |
| Engine Type |
ICE |
| Piston Series |
SRP |
| Second Compression Ring Thickness |
0.0640 |
| Ringset Included |
No |
| Oil Ring Thickness |
0.188 |
| Forging Type |
FSR |
| Piston Head Type |
Flat |
| Title - Web |
SRP Chrysler Small Block Piston Kit - 4.040 in. Bore - 1.804 in. CH, -5.00 CC |
| Piston Pin Material |
5115 |
| Piston Pin Length |
2.750 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chrysler |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
