Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Big Block 460 M-6049-SCJ |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
SRP, Ford, Big Block Ford, 4.390 in. Bore, 1.350 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.390 Bore, 1.350 CD, 0.990 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford 460, 4.390 Bore, Dish, Set of 8 |
| Piston Pin Length |
2.930 |
| Piston Head Type |
Dish |
| Wrist Pin Outer Diameter |
0.990 |
| Forging Type |
FSR |
| Engine |
Big Block |
| Piston Series |
SRP |
| Title |
SRP - Ford, Big Block, 4.390 in. Bore, Piston Kit |
| Make |
FORD |
| Engine Type |
ICE |
| Ringset Included |
No |
| Piston Pin Material |
5115 |
| Compression Height |
1.350 |
| Oil Ring Thickness |
0.218 |
| Piston Pin Wall Thickness |
0.150 |
| Engine - Web |
Big Block |
| Wrist Pin Wall Thickness |
0.150 |
| Prop 65 Yes/No |
Yes |
| Second Compression Ring Thickness |
0.0640 |
| Industry |
Automotive |
| Add-On |
990-042-CS |
| Piston Pin Outside Diameter |
0.990 |
| Product Type |
Engine Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Piston Volume |
-33.00 |
| Add-On |
S100S8-4390-5 |
| Bore Diameter |
4.390 |
| Piston Average Weight |
561 |
| Piston Material |
4032 |
| Out of Stock Message |
Call for Availability |
| Product Market |
Domestic |
| Title - Web |
SRP Ford Big Block Piston Kit - 4.390 in. Bore - 1.350 in. CH, -33.00 CC |
| Add-On |
990-2930-15-51S |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Cylinder Head |
M-6049-SCJ |
| Top Compression Ring Thickness |
0.0640 |
| Make - Web |
Ford |
| Wrist Pin Length |
2.930 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
No |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
