Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 351C Cleveland |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.040 Bore, 1.200 CD, 0.927 Pin, Set of 8. |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.040 in. Bore, 1.200 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford 351 Cleveland, 4.040 Bore, Flat, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Make - Web |
Ford |
| Prop 65 (C, R or CR) |
CR |
| Ringset Included |
No |
| Piston Material |
4032 |
| Prop 65 Yes/No |
Yes |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Second Compression Ring Thickness |
0.0640 |
| Add-On |
927-2750-15-51S |
| Engine |
Small Block |
| Piston Pin Length |
2.750 |
| Industry |
Automotive |
| Cylinder Head |
CLEVELAND |
| Piston Head Type |
Flat |
| Out of Stock Message |
Call for Availability |
| Add-On |
927-042-CS |
| Add-On |
S100S8-4040-5 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Engine Type |
ICE |
| Top Compression Ring Thickness |
0.0640 |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.040 in. Bore - 1.200 in. CH, -3.00 CC |
| Compression Height |
1.200 |
| Make |
FORD |
| Forging Type |
FSR |
| Product Type |
Engine Piston Kit |
| Oil Ring Thickness |
0.218 |
| Piston Series |
SRP |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Material |
5115 |
| Piston Pin Outside Diameter |
0.927 |
| Wrist Pin Outer Diameter |
0.927 |
| Ring Set Included |
No |
| Wrist Pin Wall Thickness |
0.150 |
| Engine - Web |
Small Block |
| Wrist Pin Length |
2.750 |
| Bore Diameter |
4.040 |
| Piston Volume |
-3.00 |
| Title |
SRP - Ford, Small Block, 4.040 in. Bore, Piston Kit |
| Product Market |
Domestic |
| Piston Average Weight |
461 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
