Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Small Block 351C |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.020 Bore, 1.440 CD, 0.927 Pin, Set of 8. |
| Description_EXT |
SRP, Ford, Small Block Ford, 4.020 in. Bore, 1.440 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_TLE |
Ford 351 Cleveland, 4.020 Bore, Flat, Set of 8 |
| Prop 65 Yes/No |
Yes |
| Piston Average Weight |
499 |
| Wrist Pin Length |
2.750 |
| Ring Set Included |
No |
| Out of Stock Message |
Call for Availability |
| Piston Volume |
-3.00 |
| Product Market |
Domestic |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Bore Diameter |
4.020 |
| Second Compression Ring Thickness |
0.0640 |
| Add-On |
927-2750-15-51S |
| Top Compression Ring Thickness |
0.0640 |
| Product Type |
Engine Piston Kit |
| Title |
SRP - Ford, Small Block, 4.020 in. Bore, Piston Kit |
| Compression Height |
1.440 |
| Piston Pin Outside Diameter |
0.927 |
| Industry |
Automotive |
| Add-On |
S100S8-4020-5 |
| Cylinder Head |
CLEVELAND |
| Add-On |
927-042-CS |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Engine - Web |
Small Block |
| Piston Pin Wall Thickness |
0.150 |
| Piston Material |
4032 |
| Engine |
Small Block |
| Piston Pin Length |
2.750 |
| Ringset Included |
No |
| Engine Type |
ICE |
| Forging Type |
FSR |
| Oil Ring Thickness |
0.188 |
| Prop 65 (C, R or CR) |
CR |
| Make |
FORD |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Ford |
| Piston Pin Material |
5115 |
| Piston Head Type |
Flat |
| Title - Web |
SRP Ford Small Block Piston Kit - 4.020 in. Bore - 1.440 in. CH, -3.00 CC |
| Piston Series |
SRP |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.927 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
