Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Ford Big Block 460 M-6049-SCJ |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.440 Bore, 1.350 CD, 0.990 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Ford, Big Block Ford, 4.440 in. Bore, 1.350 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Ford 460, 4.440 Bore, Dish, Set of 8 |
| Forging Type |
FSR |
| Make |
FORD |
| Title |
SRP - Ford, Big Block, 4.440 in. Bore, Piston Kit |
| Engine Type |
ICE |
| Piston Pin Outside Diameter |
0.990 |
| Ring Set Included |
No |
| Piston Pin Material |
5115 |
| Compression Height |
1.350 |
| Product Market |
Domestic |
| Product Type |
Engine Piston Kit |
| Piston Series |
SRP |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.990 |
| Wrist Pin Length |
2.930 |
| Piston Pin Wall Thickness |
0.150 |
| Bore Diameter |
4.440 |
| Oil Ring Thickness |
0.218 |
| Piston Material |
4032 |
| Piston Volume |
-38.00 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Prop 65 (C, R or CR) |
CR |
| Top Compression Ring Thickness |
0.0640 |
| Piston Average Weight |
622 |
| Prop 65 Yes/No |
Yes |
| Engine - Web |
Big Block |
| Piston Head Type |
Dish |
| Title - Web |
SRP Ford Big Block Piston Kit - 4.440 in. Bore - 1.350 in. CH, -38.00 CC |
| Engine |
Big Block |
| Second Compression Ring Thickness |
0.0640 |
| Piston Pin Length |
2.930 |
| Industry |
Automotive |
| Cylinder Head |
SUPER COBRA JET |
| Add-On |
990-042-CS |
| Out of Stock Message |
Call for Availability |
| Add-On |
J100F8-4440-5 |
| Add-On |
990-2930-15-51S |
| Ringset Included |
No |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Ford |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
