As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet Small Block 400 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Flat Top, 4.145 Bore, 1.000 CD, 0.927 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston Kit |
| Description_EXT |
JE, Chevrolet, Small Block Chevrolet, 4.145 in. Bore, 1.000 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_TLE |
Chevrolet 400, 4.145 Bore, Flat, Set of 8 |
| Description_SHO |
Piston Kit |
| Engine Type |
ICE |
| Piston Quantity |
8 |
| Make |
CHEVROLET |
| Title |
JE Pistons - Chevrolet, Small Block, 4.145 in. Bore, Piston Kit |
| Piston Series |
JE Pistons |
| Ring Set Included |
No |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Length |
2.750 |
| Piston Pin Material |
5115 |
| Forging Type |
Round |
| Piston Pin Wall Thickness |
0.150 |
| Piston Volume |
-5.00 |
| Bore Diameter |
4.145 |
| Piston Pin Outside Diameter |
0.927 |
| Product Type |
Engine Piston Kit |
| Wrist Pin Outer Diameter |
0.927 |
| Engine - Web |
Small Block |
| Piston Average Weight |
402 |
| Ringset Included |
No |
| Piston Pin Length |
2.750 |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Prop 65 Yes/No |
Yes |
| Oil Ring Thickness |
0.218 |
| Top Compression Ring Thickness |
0.0640 |
| Compression Height |
1.000 |
| Second Compression Ring Thickness |
0.0640 |
| Prop 65 (C, R or CR) |
CR |
| Product Market |
Domestic |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Domestic |
| Piston Material |
2618 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Add-On |
927-2750-15-51S |
| Piston Head Type |
Flat |
| Title - Web |
JE Pistons Chevrolet Small Block Piston Kit - 4.145 in. Bore - 1.000 in. CH, -5.00 CC |
| Industry |
Automotive |
| Add-On |
J10008-4145-5 |
| Add-On |
927-042-CS |
| Engine |
Small Block |
| Out of Stock Message |
Call for Availability |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
