Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Big Block 454 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.530 Bore, 1.270 CD, 0.990 Pin, Set of 8. |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_INV |
SRP, Piston Set |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_EXT |
SRP, Chevrolet, Big Block Chevrolet, 4.530 in. Bore, 1.270 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 454, 4.530 Bore, Dish, Set of 8 |
| Piston Head Type |
Dish |
| Product Type |
Engine Piston Kit |
| Engine Type |
ICE |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Outside Diameter |
0.990 |
| Wrist Pin Length |
2.930 |
| Piston Pin Material |
5115 |
| Forging Type |
FSR |
| Wrist Pin Wall Thickness |
0.150 |
| Piston Series |
SRP |
| Ring Set Included |
No |
| Compression Height |
1.270 |
| Oil Ring Thickness |
0.218 |
| Top Compression Ring Thickness |
0.0640 |
| Bore Diameter |
4.530 |
| Product Market |
Domestic |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Volume |
-9.00 |
| Make |
CHEVROLET |
| Engine - Web |
Big Block |
| Cylinder Head |
OPEN CHAMBER |
| Piston Average Weight |
607 |
| Second Compression Ring Thickness |
0.0640 |
| Prop 65 (C, R or CR) |
CR |
| Ringset Included |
No |
| Piston Material |
4032 |
| Title - Web |
SRP Chevrolet Big Block Piston Kit - 4.530 in. Bore - 1.270 in. CH, -9.00 CC |
| Prop 65 Yes/No |
Yes |
| Title |
SRP - Chevrolet, Big Block, 4.530 in. Bore, Piston Kit |
| Wrist Pin Outer Diameter |
0.990 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Industry |
Automotive |
| Add-On |
S100S8-4530-5 |
| Add-On |
990-2930-15-51S |
| Out of Stock Message |
Call for Availability |
| Piston Pin Length |
2.930 |
| Add-On |
990-042-CS |
| Engine |
Big Block |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
15.0000 |
