Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.000 Bore, 1.550 CD, 0.927 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_EXT |
SRP, Chevrolet, Small Block Chevrolet, 4.000 in. Bore, 1.550 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_TLE |
Chevrolet 350, 4.000 Bore, Flat, Set of 8 |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Piston Head Type |
Flat |
| Piston Pin Outside Diameter |
0.927 |
| Piston Series |
SRP |
| Engine Type |
ICE |
| Wrist Pin Outer Diameter |
0.927 |
| Forging Type |
FSR |
| Oil Ring Thickness |
0.188 |
| Product Market |
Domestic |
| Ringset Included |
No |
| Title |
SRP - Chevrolet, Small Block, 4.000 in. Bore, Piston Kit |
| Make |
CHEVROLET |
| Engine |
Small Block |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Piston Pin Wall Thickness |
0.150 |
| Top Compression Ring Thickness |
0.0640 |
| Prop 65 (C, R or CR) |
CR |
| Compression Height |
1.550 |
| Piston Pin Material |
5115 |
| Bore Diameter |
4.000 |
| Cylinder Head |
STD CHEVROLET 23 DEG |
| Piston Material |
4032 |
| Engine - Web |
Small Block |
| Wrist Pin Wall Thickness |
0.150 |
| Out of Stock Message |
Call for Availability |
| Second Compression Ring Thickness |
0.0640 |
| Prop 65 Yes/No |
Yes |
| Product Type |
Engine Piston Kit |
| Title - Web |
SRP Chevrolet Small Block Piston Kit - 4.000 in. Bore - 1.550 in. CH, -4.00 CC |
| Add-On |
927-042-CS |
| Add-On |
927-2500-15-51S |
| Industry |
Automotive |
| Piston Pin Length |
2.500 |
| Piston Volume |
-4.00 |
| Add-On |
S100S8-4000-5 |
| Wrist Pin Length |
2.500 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Ring Set Included |
No |
| Make - Web |
Chevrolet |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
12.0000 |
