Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Small Block 340 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.070 Bore, 1.460 CD, 0.984 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chrysler, Small Block Chrysler, 4.070 in. Bore, 1.460 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_TLE |
Chrysler 340, 4.070 Bore, Dish, Set of 8 |
| Description_SHO |
Piston Kit |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Engine |
Small Block |
| Product Type |
Engine Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Ring Set Included |
No |
| Add-On |
984-2750-15-51S |
| Prop 65 Yes/No |
Yes |
| Add-On |
990-042-CS |
| Piston Pin Length |
2.750 |
| Out of Stock Message |
Call for Availability |
| Add-On |
J100F8-4070-5 |
| Second Compression Ring Thickness |
0.0640 |
| Piston Head Type |
Dish |
| Make |
CHRYSLER |
| Piston Series |
SRP |
| Cylinder Head |
340 WEDGE |
| Title - Web |
SRP Chrysler Small Block Piston Kit - 4.070 in. Bore - 1.460 in. CH, -16.90 CC |
| Piston Volume |
-16.90 |
| Piston Material |
4032 |
| Industry |
Automotive |
| Make - Web |
Chrysler |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Piston Pin Outside Diameter |
0.984 |
| Forging Type |
FSR |
| Bore Diameter |
4.070 |
| Title |
SRP - Chrysler, Small Block, 4.070 in. Bore, Piston Kit |
| Piston Pin Wall Thickness |
0.150 |
| Product Market |
Domestic |
| Ringset Included |
No |
| Engine Type |
ICE |
| Compression Height |
1.460 |
| Piston Average Weight |
474 |
| Oil Ring Thickness |
0.188 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Top Compression Ring Thickness |
0.0640 |
| Piston Pin Material |
5115 |
| Wrist Pin Wall Thickness |
0.150 |
| Engine - Web |
Small Block |
| Wrist Pin Length |
2.750 |
| Wrist Pin Outer Diameter |
0.984 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
