Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chrysler Small Block 340 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.060 Bore, 1.460 CD, 0.984 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_EXT |
SRP, Chrysler, Small Block Chrysler, 4.060 in. Bore, 1.460 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_INV |
SRP, Piston Set |
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chrysler 340, 4.060 Bore, Dish, Set of 8 |
| Product Market |
Domestic |
| Top Compression Ring Thickness |
0.0640 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Bore Diameter |
4.060 |
| Compression Height |
1.460 |
| Industry |
Automotive |
| Piston Material |
4032 |
| Piston Average Weight |
470 |
| Title |
SRP - Chrysler, Small Block, 4.060 in. Bore, Piston Kit |
| Ring Set Included |
No |
| Engine - Web |
Small Block |
| Make |
CHRYSLER |
| Add-On |
S100S8-4060-5 |
| Prop 65 (C, R or CR) |
CR |
| Product Type |
Engine Piston Kit |
| Out of Stock Message |
Call for Availability |
| Piston Pin Outside Diameter |
0.984 |
| Cylinder Head |
340 WEDGE |
| Piston Volume |
-16.90 |
| Prop 65 Yes/No |
Yes |
| Add-On |
984-2750-15-51S |
| Add-On |
990-042-CS |
| Second Compression Ring Thickness |
0.0640 |
| Make - Web |
Chrysler |
| Wrist Pin Length |
2.750 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Title - Web |
SRP Chrysler Small Block Piston Kit - 4.060 in. Bore - 1.460 in. CH, -16.90 CC |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Material |
5115 |
| Oil Ring Thickness |
0.188 |
| Engine |
Small Block |
| Piston Series |
SRP |
| Engine Type |
ICE |
| Piston Head Type |
Dish |
| Forging Type |
FSR |
| Ringset Included |
No |
| Piston Pin Length |
2.750 |
| Wrist Pin Outer Diameter |
0.984 |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
