Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 400 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Inv Dome/Dish, 4.135 Bore, 1.125 CD, 0.927 Pin, Set of 8. |
| Description_INV |
SRP, Piston Set |
| Description_EXT |
SRP, Chevrolet, Small Block Chevrolet, 4.135 in. Bore, 1.125 CD, Inverted Dome/Dish, 8 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Dedicated forging helps optimize strength and weight throughout the piston design
- Perfect for street/strip applications
- Forced pin oiling for improved pin lubrication
- Made 100% in the USA
|
| Description_MKT |
Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 400, 4.135 Bore, Dish, Set of 8 |
| Piston Pin Length |
2.750 |
| Piston Average Weight |
418 |
| Category Hierarchy |
Auto>SRP Pistons>SRP>Piston Kits |
| Product Type |
Engine Piston Kit |
| Prop 65 (C, R or CR) |
CR |
| Piston Volume |
-16.00 |
| Industry |
Automotive |
| Wrist Pin Length |
2.750 |
| Ring Set Included |
No |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Out of Stock Message |
Call for Availability |
| Title - Web |
SRP Chevrolet Small Block Piston Kit - 4.135 in. Bore - 1.125 in. CH, -16.00 CC |
| Add-On |
927-042-CS |
| Prop 65 Yes/No |
Yes |
| Add-On |
927-2750-15-51S |
| Add-On |
J100F8-4135-5 |
| Second Compression Ring Thickness |
0.0640 |
| Piston Material |
4032 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Piston Pin Wall Thickness |
0.150 |
| Ringset Included |
No |
| Piston Series |
SRP |
| Engine Type |
ICE |
| Compression Height |
1.125 |
| Oil Ring Thickness |
0.218 |
| Engine |
Small Block |
| Bore Diameter |
4.135 |
| Piston Pin Outside Diameter |
0.927 |
| Forging Type |
FSR |
| Title |
SRP - Chevrolet, Small Block, 4.135 in. Bore, Piston Kit |
| Top Compression Ring Thickness |
0.0640 |
| Make |
CHEVROLET |
| Product Market |
Domestic |
| Piston Head Type |
Dish |
| Piston Pin Material |
5115 |
| Engine - Web |
Small Block |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.927 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
14.0000 |
