SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet Small Block 350 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Dome, 4.000 Bore, 1.260 CD, 0.927 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_INV |
SRP Pro, Piston Set |
| Description_EXT |
SRP Pro 4032, Chevrolet, Small Block Chevrolet, 4.000 in. Bore, 1.260 CD, Dome, 8 Cyl. Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Chevrolet 350, 4.000 Bore, Dome, Set of 8 |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Title - Web |
SRP Pro 4032 Chevrolet Small Block Piston Kit - 4.000 in. Bore - 1.260 in. CH, 11.00 CC |
| Add-On |
927-2250-15-51C |
| Add-On |
JG3101-4000-7 |
| Add-On |
927-073-MW |
| Engine Type |
ICE |
| Forging Type |
FSR |
| Piston Pin Length |
2.250 |
| Engine |
Small Block |
| Out of Stock Message |
Call for Availability |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Prop 65 Yes/No |
Yes |
| Piston Series |
SRP Pro 4032 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Pin Outside Diameter |
0.927 |
| Ringset Included |
Yes |
| Piston Head Type |
Dome |
| Second Compression Ring Thickness |
0.0600 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Outer Diameter |
0.927 |
| Engine - Web |
Small Block |
| Make - Web |
Chevrolet |
| Top Compression Ring Thickness |
0.0480 |
| Title |
SRP Pro 4032 - Chevrolet, Small Block, 4.000 in. Bore, Piston Kit |
| Cylinder Head |
CHEVROLET 23 DEG 20/30 |
| Make |
CHEVROLET |
| Oil Ring Thickness |
0.119 |
| Piston Average Weight |
436 |
| Industry |
Automotive |
| Compression Height |
1.260 |
| Piston Pin Material |
5115 |
| Product Market |
Domestic |
| Piston Material |
4032 |
| Piston Volume |
11.00 |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Prop 65 (C, R or CR) |
CR |
| Product Type |
Engine Piston Kit |
| Bore Diameter |
4.000 |
| Ring Set Included |
Yes |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Length |
2.250 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
12.0000 |
