SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA.
Specifications:
| Description_ASM |
Chevrolet LS2 |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 4032, Flat Top, 4.000 Bore, 1.340 CD, 0.945 Pin, Set of 8. |
| Description_FAB |
- Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Low-friction skirt coating reduces wear and reduces operating noise while optimizing performance
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Accumulator groove helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_EXT |
SRP Pro 4032, Chevrolet, LS Gen III/IV, 4.000 in. Bore, 1.340 CD, Flat Top, 8 Cyl. Piston Kit |
| Description_INV |
SRP Pro, Piston Set |
| Description_TLE |
Chevrolet LS2, 4.000 Bore, Flat, Set of 8 |
| Description_MKT |
SRP Professional pistons combine forged piston durability with modern performance technology for an extremely capable forged piston kit that doesn?t break the bank. Forged from 4032 aluminum, SPR Pro pistons experience minimal thermal expansion, making them perfect for a high-performance, reliable engine build from the track to the drag strip. All SRP Pro pistons include premium ring sets, wrist pins and locks. As with all JE Pistons products, SRP pistons are made 100% in the USA. |
| Description_SHO |
Piston Kit |
| Piston Volume |
-5.00 |
| Product Type |
Engine Piston Kit |
| Cylinder Head |
LSX/L92 12 DEG |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Second Compression Ring Thickness |
0.0600 |
| Out of Stock Message |
Call for Availability |
| Category Hierarchy |
Auto>SRP Pistons>SRP Pro>Piston Kits |
| Title - Web |
SRP Pro 4032 Chevrolet LS Gen III/IV Piston Kit - 4.000 in. Bore - 1.330 in. CH, -5.00 CC |
| Add-On |
JG3101-4000-7 |
| Industry |
Automotive |
| Bore Diameter |
4.000 |
| Piston Material |
4032 |
| Add-On |
945-073-MW |
| Piston Average Weight |
420 |
| Add-On |
945-2250-15-51C |
| Prop 65 (C, R or CR) |
CR |
| Top Compression Ring Thickness |
0.0480 |
| Piston Pin Outside Diameter |
0.945 |
| Ringset Included |
Yes |
| Piston Series |
SRP Pro 4032 |
| Piston Head Type |
Flat |
| Prop 65 Yes/No |
Yes |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Make - Web |
Chevrolet |
| Title |
SRP Pro 4032 - Chevrolet, LS Gen III/IV, 4.000 in. Bore, Piston Kit |
| Product Market |
Domestic |
| Piston Pin Wall Thickness |
0.150 |
| Make |
CHEVROLET |
| Engine Type |
ICE |
| Compression Height |
1.330 |
| Piston Pin Material |
5115 |
| Forging Type |
FSR |
| Piston Pin Length |
2.250 |
| Oil Ring Thickness |
0.119 |
| Engine |
LS Gen III/IV |
| Engine - Web |
LS Gen III/IV |
| Wrist Pin Outer Diameter |
0.945 |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
13.0000 |
