As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Toyota 2JZ-GTE/2JZ-GE |
| Description_DEF |
Engine Piston Kit |
| Description_DES |
Piston Set, 2618, Inv Dome/Dish, 3.386 Bore, 1.181 CD, 0.866 Pin, Set of 6. |
| Description_EXT |
JE, Toyota, 2JZ-GTE, 3.386 in. Bore, 8.50:1, Inverted Dome/Dish, 6 Cyl. Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_SHO |
Piston Kit |
| Description_TLE |
Toyota 2JZ-GE/2JZ-GTE, 86.00 Bore, Dish, Set of 6 |
| Title |
JE Pistons - Toyota, 2JZ-GTE, 86.00 mm Bore, Piston Kit |
| Out of Stock Message |
Call for Availability |
| Piston Volume |
-21.90 |
| Bore Diameter |
86.00 |
| Piston Average Weight |
290 |
| Title - Web |
JE Pistons Toyota 2JZ-GTE Piston Kit - 86.00 mm Bore - 1.181 in. CH, -21.90 CC |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Product Market |
Sport Compact |
| Add-On |
866-2250-15-51C |
| Add-On |
866-063-MW |
| Piston Pin Outside Diameter |
0.866 |
| Add-On |
JG1001-3386 |
| Industry |
Automotive |
| Top Compression Ring Thickness |
0.0400 |
| Compression Height |
1.181 |
| Prop 65 Yes/No |
Yes |
| Piston Quantity |
6 |
| Product Type |
Engine Piston Kit |
| Second Compression Ring Thickness |
0.0480 |
| Piston Pin Length |
2.250 |
| Oil Ring Thickness |
0.141 |
| Cylinder Head |
2JZ-GTE |
| Prop 65 (C, R or CR) |
CR |
| Piston Material |
2618 |
| Ringset Included |
Yes |
| Engine |
2JZ-GTE |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Engine - Web |
2JZ-GTE |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Make - Web |
Toyota |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Engine Type |
ICE |
| Make |
TOYOTA |
| Piston Pin Wall Thickness |
0.150 |
| Forging Type |
FSR |
| Piston Pin Material |
5115 |
| Piston Head Type |
Dish |
| Piston Series |
JE Pistons |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Outer Diameter |
0.866 |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
12.0000 |
| Weight |
5.0000 |
