As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Toyota 1FZ-FE |
| Description_DES |
Piston Set, 2618, Dome, 3.976 Bore, 1.653 CD, 1.024 Pin, Set of 6. |
| Description_DEF |
Engine Piston Kit |
| Description_EXT |
JE, Toyota, 1FZ-FE, 3.976 in. Bore, 10.00:1, Dome, 6 Cyl. Piston Kit |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_INV |
JE Pistons, Piston Kit |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_SHO |
Piston Kit |
| Description_TLE |
Toyota 1FZ-FE, 101.00 Bore, Dome, Set of 6 |
| Compression Height |
1.653 |
| Wrist Pin Outer Diameter |
1.024 |
| Prop 65 (C, R or CR) |
CR |
| Piston Pin Outside Diameter |
1.024 |
| Make |
TOYOTA |
| Ring Set Included |
Yes |
| Engine - Web |
1FZ-FE |
| Wrist Pin Length |
2.500 |
| Category Hierarchy |
Auto>JE Pistons>Piston Kits>Sport Compact |
| Add-On |
031-042-CS |
| Prop 65 Yes/No |
Yes |
| Industry |
Automotive |
| Top Compression Ring Thickness |
0.0400 |
| Add-On |
024-2500-20-51S |
| Piston Pin Wall Thickness |
0.200 |
| Product Type |
Engine Piston Kit |
| Bore Diameter |
101.00 |
| Product Market |
Sport Compact |
| Cylinder Head |
1FZ-FE |
| Piston Quantity |
6 |
| Add-On |
JG1001-3976 |
| Piston Head Type |
Dome |
| Engine |
1FZ-FE |
| Piston Pin Length |
2.500 |
| Title |
JE Pistons - Toyota, 1FZ-FE, 101.00 mm Bore, Piston Kit |
| Out of Stock Message |
Call for Availability |
| Piston Average Weight |
497 |
| Piston Volume |
4.30 |
| Title - Web |
JE Pistons Toyota 1FZ-FE Piston Kit - 101.00 mm Bore - 1.653 in. CH, 4.30 CC |
| Piston Material |
2618 |
| Engine Type |
ICE |
| Wrist Pin Wall Thickness |
0.200 |
| Oil Ring Thickness |
0.111 |
| Piston Series |
JE Pistons |
| Second Compression Ring Thickness |
0.0480 |
| Ringset Included |
Yes |
| Forging Type |
Round |
| Piston Pin Material |
5115 |
| Make - Web |
Toyota |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
6.0000 |
| Width |
12.0000 |
| Height |
26.0000 |
| Weight |
5.0000 |
