As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan VQ35HR |
| Description_DEF |
Engine Piston |
| Description_DES |
Piston Single, 2618, Dome, 3.760 Bore, 1.198 CD, 0.866 Pin, Set of 1. |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_EXT |
JE, Nissan, VQ35HR, 3.760 in. Bore, 11.50:1, Dome, Left Piston |
| Description_SHO |
Piston |
| Description_TLE |
Nissan VQ35HR, 95.50 Bore, Dome, Set of 1 |
| Add-On |
866-063-MW |
| Add-On |
JG1001-3760 |
| Add-On |
866-2250-15-51C |
| Compression Height |
1.198 |
| Bore Diameter |
95.50 |
| Cylinder Head |
VQ35HR |
| Engine |
VQ35HR |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
| Piston Pin Length |
2.250 |
| Piston Orientation |
Left |
| Piston Pin Material |
5115 |
| Piston Volume |
9.20 |
| Piston Pin Outside Diameter |
0.866 |
| Piston Average Weight |
409 |
| Forging Type |
FSR |
| Product Market |
Sport Compact |
| Piston Series |
JE Pistons |
| Out of Stock Message |
Call for Availability |
| Piston Head Type |
Dome |
| Industry |
Automotive |
| Engine Type |
ICE |
| Piston Material |
2618 |
| Make |
NISSAN |
| Oil Ring Thickness |
0.111 |
| Piston Quantity |
1 |
| Piston Pin Wall Thickness |
0.150 |
| Make - Web |
Nissan |
| Engine - Web |
VQ35HR |
| Product Type |
Engine Piston |
| Ringset Included |
Yes |
| Prop 65 Yes/No |
Yes |
| Title - Web |
JE Pistons Nissan VQ35HR Piston - 95.50 mm Bore - 1.198 in. CH, 9.20 CC |
| Prop 65 (C, R or CR) |
CR |
| Title |
JE Pistons - Nissan, VQ35HR, 95.50 mm Bore, Piston |
| Top Compression Ring Thickness |
0.0400 |
| Second Compression Ring Thickness |
0.0480 |
| Wrist Pin Length |
2.250 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Ring Set Included |
Yes |
| Wrist Pin Outer Diameter |
0.866 |
| Wrist Pin Wall Thickness |
0.150 |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
