As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Chevrolet LS1 |
| Description_DES |
Piston Single, 2618, Flat Top, 3.898 Bore, 1.175 CD, 0.927 Pin, Set of 1. |
| Description_DEF |
Engine Piston |
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for domestic applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From dirt track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_INV |
JE Pistons, Piston |
| Description_EXT |
JE, Chevrolet, LS Gen III/IV, 3.898 in. Bore, 1.175 CD, Flat Top, Left Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Made 100% in the USA
|
| Description_TLE |
Chevrolet LS1, 3.898 Bore, Flat, Set of 1 |
| Description_SHO |
Piston |
| Add-On |
927-2250-15-51C |
| Add-On |
J68008-3900-3 |
| Add-On |
927-073-MW |
| Compression Height |
1.175 |
| Engine |
LS Gen III/IV |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Domestic |
| Bore Diameter |
3.898 |
| Cylinder Head |
LSX/L92 12 DEG |
| Ringset Included |
No |
| Industry |
Automotive |
| Piston Series |
JE Pistons |
| Prop 65 Yes/No |
Yes |
| Piston Volume |
-2.00 |
| Second Compression Ring Thickness |
0.0600 |
| Piston Pin Material |
5115 |
| Piston Orientation |
Left |
| Piston Material |
2618 |
| Piston Average Weight |
421 |
| Top Compression Ring Thickness |
0.0600 |
| Title |
JE Pistons - Chevrolet, LS Gen III/IV, 3.898 in. Bore, Piston |
| Piston Pin Outside Diameter |
0.927 |
| Product Market |
Domestic |
| Piston Pin Length |
2.250 |
| Forging Type |
FSR |
| Title - Web |
JE Pistons Chevrolet LS Gen III/IV Piston - 3.898 in. Bore - 1.175 in. CH, -2.00 CC |
| Product Type |
Engine Piston |
| Piston Pin Wall Thickness |
0.150 |
| Prop 65 (C, R or CR) |
CR |
| Piston Head Type |
Flat |
| Piston Quantity |
1 |
| Oil Ring Thickness |
0.1175 |
| Out of Stock Message |
Call for Availability |
| Engine Type |
ICE |
| Make |
CHEVROLET |
| Wrist Pin Length |
2.250 |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Wrist Pin Outer Diameter |
0.927 |
| Make - Web |
Chevrolet |
| Ring Set Included |
No |
| Engine - Web |
LS Gen III/IV |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
2.0000 |
