As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Specifications:
| Description_ASM |
Nissan VQ35HR |
| Description_DES |
Piston Single, 2618, Inv Dome/Dish, 3.780 Bore, 1.198 CD, 0.866 Pin, Set of 1. |
| Description_DEF |
Engine Piston |
| Description_EXT |
JE, Nissan, VQ35HR, 3.779 in. Bore, 8.50:1, Inverted Dome/Dish, Left Piston |
| Description_INV |
JE Pistons, Piston |
| Description_FAB |
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
- Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
- Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
- Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
- Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
- Made 100% in the USA
|
| Description_MKT |
As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons? performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons. |
| Description_TLE |
Nissan VQ35HR, 96.00 Bore, Dish, Set of 1 |
| Description_SHO |
Piston |
| Add-On |
866-2250-15-51C |
| Category Hierarchy |
Auto>JE Pistons>Single Replacement Pistons>Sport Compact |
| Compression Height |
1.198 |
| Bore Diameter |
96.00 |
| Add-On |
JG1001-3780 |
| Cylinder Head |
VQ35HR |
| Add-On |
866-063-MW |
| Product Market |
Sport Compact |
| Piston Orientation |
Left |
| Piston Material |
2618 |
| Oil Ring Thickness |
0.111 |
| Make |
NISSAN |
| Piston Average Weight |
374 |
| Piston Pin Material |
5115 |
| Industry |
Automotive |
| Piston Quantity |
1 |
| Piston Pin Wall Thickness |
0.150 |
| Piston Head Type |
Dish |
| Piston Pin Outside Diameter |
0.866 |
| Engine Type |
ICE |
| Forging Type |
FSR |
| Engine |
VQ35HR |
| Piston Volume |
-13.70 |
| Piston Series |
JE Pistons |
| Out of Stock Message |
Call for Availability |
| Piston Pin Length |
2.250 |
| Make - Web |
Nissan |
| Engine - Web |
VQ35HR |
| Prop 65 Yes/No |
Yes |
| Title |
JE Pistons - Nissan, VQ35HR, 96.00 mm Bore, Piston |
| Product Type |
Engine Piston |
| Top Compression Ring Thickness |
0.0400 |
| Title - Web |
JE Pistons Nissan VQ35HR Piston - 96.00 mm Bore - 1.198 in. CH, -13.70 CC |
| Prop 65 (C, R or CR) |
CR |
| Ringset Included |
Yes |
| Second Compression Ring Thickness |
0.0480 |
| Wrist Pin Outer Diameter |
0.866 |
| Prop 65 - Short Label |
Prop 65 Warning Label.JPG |
| Wrist Pin Length |
2.250 |
| Ring Set Included |
Yes |
| Wrist Pin Wall Thickness |
0.150 |
| Wrist Pin Material |
5115 Low Carbon Steel, Case Hardened |
| Length |
5.0000 |
| Width |
5.0000 |
| Height |
5.0000 |
| Weight |
1.0000 |
